Vishay Semiconductors Automotive TVS/ESD Diodes
Vishay Semiconductors Automotive TVS/ESD Diodes are AEC-Q101-qualified devices that provide a high surge capability of 400W at 10/1000μs for portable electronics. These modules feature a low 1mm profile, low noise technology, and fast response times. Vishay Semiconductors Automotive TVS/ESD Diodes are ideal for line transient voltage protection in space-constrained electronics, such as laptops, notebooks, tablets, smartphones, and external hard drives.
Features
- AEC-Q101 qualified available
- Symmetrical leads, low-profile packages
- Low capacitance
- High power surge capability up to 5kW and 3kW at 10/1000µs
Applications
- Automotive
- Consumer electronics
- Industrial
- Computers
- External hard drives
Videos
Infographic
Resources
- What is a Silicon Transient Voltage Suppressor?
- Failure Modes and Fusing of TVS Devices
- Effect of Lead Wire Lengths on Protector Clamping Voltages
- Hardening Power Supplies to Line Voltage Transients
- Find the Right ESD or TVS Diode
- Determining Clamping Voltage Levels for a Broad Range of Pulse Currents
- Protecting Low Current Loads in Harsh Electrical Environments
- TVS Placement - The Critical Path to the Leading Edge
Featured Products
Vishay Semiconductors VCAN24A2 BiSy Dual-Line ESD Protection Diodes
Ideal for automotive applications in a small DFN1110-3A package.
Vishay Semiconductors VCAN36A2-03G & VCAN36A2-03S ESD Protection Diodes
BiSy dual-line ESD protection diodes in SOT-23 & SOT-323 packages, with AEC-Q101 options available.
Vishay General Semiconductor SMC3K TransZorb® TVS Diodes
TransZorb® Bi-Directional TVS Diodes feature high surge capability to 3kW.
Vishay SMFxxA ESD Protection Diodes
Feature high surge capability of 200W at 10/1000µs and low incremental surge resistance.
Vishay Bidirectional Symmetrical ESD-Protection Diodes
Space-saving single line or dual-line diodes that offer low capacitance and leakage current.
Vishay Semiconductors VCUT07B1-HD1 BiSy ESD-Protection Diode
Clamps positive and negative overvoltage transients to ground, small LLP1006-2L package.
Vishay Semiconductors BiSy CLP ESD Protection Diodes
Feature 1-line or 2-line ESD protection with working voltages of ±3.3V, ±5.5V, ±10V ±15V, or ±26.5V
Vishay VBUS05B1-SD0 Single Line ESD Protection Diode
ESD protection device that clamps positive and negative overvoltage transients to a ground.
Vishay Semiconductors eSMP® SMF ESD/TVS Diodes
Surface-mount devices with low-profile 1mm SMF package & high surge capability of 200W at 10/1000µs.
Vishay General Semiconductor SMC5K TRANSZORB TVS Diodes
Unidirectional, peak pulse power of 5000W (10/1000μs) or 40kW (8/20μs), AEC-Q101-qualified.
Vishay General Semiconductor TVS serie SMBJxxD
Ideal para colocación automatizada con un ± 3,5%, con una tolerancia de VBR muy ajustada y unidireccional.
Vishay General Semiconductor eSMP® SlimSMA TVS Diodes
Low 0.95mm profile for automated placement, excellent clamping capability, 600W peak pulse power.
Vishay General Semiconductor eSMP® MicroSMP TransZorb® TVS Diodes
Improved reliability & longer operational lifespan in small 2.5mm x 1.3mm footprint & 0.65mm height.
Vishay General Semiconductor eSMP® SMPC TVS Diodes
1500W, surface-mount devices 27% smaller footprint than the traditional SMC package.
Vishay General Semiconductor eSMP® SMP TVS Diodes
Single-chip, SMD package (DO-220AA), used as a higher-performance upgrade to existing devices.
Vishay Optical Encoders/Digital Potentiometers
Electromechanical device that converts angular position or motion of an encoder to a digital code.
Vishay Semiconductors VGSOT ESD Protection Diodes
Offers low thermal resistance and extended current and power ratings in a SOT-23 package.
